VSHGM SERIES NEW RING ROLLER MILL
VSHGM SERIES NEW RING ROLLER MILL
VSHGM series new intelligent ring roller mill is developed by Dongguan Vsunny Machinery Co.,Ltd. Drawing on the same type of roller mills at home and abroad, in combination with its pratical problems encountered in using this type of mill. The main materials have been improved so it is characterized by more pratical, higher output, and longer life of wear parts. Without the drying system, it can grind all kinds of qualified non-metallic mineral powder materials with moisture less than 6%.
Quantity
- Introduction
- Specifications
| Model & Parameter index | VSHM-968 | VSHM-988 | VSHM-998 | |
| Feed particles (mm) | ≤20 | ≤20 | ≤20 | |
| Moisture of the feed (%) | ≤8% | ≤8% | ≤8% | |
| Power consumption （KW） | Main unit | 37~45 | 45~75 | 132~185 |
| Classifying machine | 7.5~15 | 11~18.5 | 11~30 | |
| blower | 30 | 30~55 | 45~75 | |
| Feeder | 1.1 | 2.2 | 2.2 | |
| Discharging screw | 1.1 | 2.2 | 2.2 | |
| Compressed air volume (M3) | 1~2 | 1~2 | 2~3 | |
| Production capacity (t/h) | 600 mesh | 1.4~1.7 | 2.1~2.3 | 4.0~4.3 |
| 800 mesh | 0.9~1.1 | 1.7~2.2 | 3.7~4.1 | |
| 1250 mesh | 0.7~1.0 | 1.3~1.7 | 2.3~2.4 | |
| 1500 mesh | 0.5~0.8 | 0.9~1.1 | 1.6~2.0 | |
| 1800 mesh | 0.4~0.6 | 0.7~0.9 | 1.3~1.7 | |
| 2500 mesh | 0.3~0.5 | 0.6~0.8 | 1.1~1.3 | |
| 3000 mesh | 0.2~0.4 | 0.5~0.7 | 1.0~1.2 | |
